Really Right Stuff Anvil-30 ARC Ball Head with 3 Series Platform Adapter

UPC 818413022126

Out of Stock

Phone Ask an expert

Talk to our experts for the best deals & pricing!


Create Wishlist

The Rapid-Lock (R-LOCK) feature in the clamp is a 5mm pin that mates with corresponding R-LOCK holes in the rail. The pin is spring-loaded to automatically engage the R-LOCK holes or be pushed down by non-R-LOCK rails, making it compatible with a wider range of “arca-type” rails. Users also have the option to disengage the pin at their discretion for rapid re-positioning. Note: Removing the R-Lock butterfly latch and index pin will allow for similar function as the Gen 1 Anvil.The Anvil-30 ARC Ball head is purpose-built for heavy equipment support from the ground up. The patent-pending dual clamp system is able to clamp both the RRS Dovetail standard and Picatinny rails in the same unit. The extra knobs/adjustment settings that were under-utilized in the industry were removed. The Anvil-30 ARC is as rigid as a leveling base but articulates like the popular photography ball heads while minimizing the limitations of each system. It was designed as a lightweight setup and realized its heavy duty potential.

R-LOCK System adds unique safety-stop features which are built in to both a mounting rail and quick-release clamp that adhere to the RRS 1.5” Standard. The advantage of the System is users have multiple “hard-stop” positions along the rail while retaining smooth edges and corners for maximum ergonomics and a snag-free interface that is inherently resistant to wearing down. The ”hard-stop” feature is comprised of a 5mm diameter steel pin that engages 5.5mm diameter holes in the rail. In addition to supplementing the traditional friction-based clamping mechanism, the interface prevents unintentional repositioning of the rail within the clamp when the R-LOCK is engaged.

  • Adjustable clamp jaw allows compatibility with many other arca-type rails that are not in spec with the RRS 1.5" Dovetail Standard
  • Patent Pending Dual lever-release clamp for fast and easy mounting on RRS Dovetail and Picatinny sections
  • Ergonomic design gives superior handling and unsurpassed reliability
  • Stronger, lighter, faster than anything we have seen on the market
  • Re-positionable lever-release for a variety of situations
  • Highly-visible level embedded in both front and back sides of the main ball body for left and right-handed users
  • Laser-engraved millimeter scale offers precise centering and positioning within the clamp jaw
  • All components are of the finest RRS quality, machined from solid aircraft aluminum or stainless steel for maximum durability and minimum weight

Product Includes

  • SOAR Anvil-30 ARC Ball head
  • 3 Series Tripod Adapter
  • Padded Cordura pouch with drawstring closure
  • 9/64" hex key (required to remove/replace ballhead from tripod) and (4) 8-32 stainless steel socket head cap screws when buying with one of the options; not included with ball head only
  • User's guide for ball head and clamp features


Load Capacity: 35 ft-lbs/ kg
Height: 2.67"/ 6.78cm
Width: 2.51"/ 6.37cm
Length: 2.85"/ 7.23cm
Ball Diameter: 30mm
Tripod Mount: 3/8"-16
Weight: 15.2oz/ 433g
Warranty may be voided: warranty is voided after it takes more than 25lbs of force to close the handle on a scale, or if deformation of metal at hinge points, in-house repair discretion


Additional Information

UPC 818413022126
Weight 1.00 LBS
